Order / Calculation example:
Order no. for a round rod with rollers and a length of 1034 mm = 1049-U18-L 1034
Internal Reference:
1049-U18-08
Product Type:
Rod
Program:
1049
Material of the module :
Steel
Surface of the module:
zinc-plated
Connecting rod position:
Inside the sealing, top or bottom
Number of Possible Locking Points:
2 points, 3 point
Mounting Positions :
Inside the sealing
Dimension L up to:
750 mm
Dimension L from:
701 mm
Length(L-dimension):
701 - 750 mm
Round bar inside the seal:
Round rod with roller and butt
No Specifications
View All Products
Here you can find the product data sheets and CAD files of this product
